Suitable for mixing different materials with similar grain and density

  • Designed for drying up water existed on surface of materials.

  • A drying mixer suitable for water-ring pellet cut, under-water pelletizing and plastic waste recycling in extruding process.

  • A multi-function machine provides hot-air drying, contact heat transfer drying and mixing functions.

  • Range of drying mixing weight: 500~3000kgs ( Custom weight is available )

  • hot_air_p_s.jpg

SPECIFICATIONS:
ModelCapacityMixing cWeight Motor(Blower)Elec.HeaterMachine Dimensions(L×W×H)
VDM-500830 Liters500 kgs3HP
(1/2HP×2)
14Kw1580x 1650x 2400 mm
VDM-10001680 Liters1000 kgs5HP
(1/2HP×2)or(1/2HP×4)
16Kw(28Kw)1580x 1650x 2400 mm
VDM-15002500 Liters1500 kgs5HP
(1/2HP×2)or(1/2HP×4)
16Kw(28Kw)2060x 2100x 3300 mm
VDM-20003400 Liters2000 kgs7.5HP
(1/2HP×2)or(1/2HP×4)
18Kw(32Kw)2260x 2300x 3450 mm
VDM-25004200 Liters2500 kgs7.5HP
(1/2HP×2)or(1/2HP×4)
20Kw(32Kw)2450x 2450x 3650 mm
VDM-30005000 Liters3000 kgs10HP
(1/2HP×4)
28Kw(32Kw)2500x 2600x 3850 mm

※ Specifications and design characteristics are subject to change without prior notice.
