Suitable for mixing different materials with similar grain and density.

  • Suitable for pre-processing or after-processing of extruding and injection operation.

  • Small horsepower consumption.
    High mixing efficiency.

  • Range of mixing weight: 200~10000kgs ( Custom weight is available )

  • vertical_p_s.jpg

SPECIFICATIONS:
ModelCapacityMixing cWeight MotorMachine Dimensions(L×W×H)
VBM-200340 Liters200 kgs2HP1100 mm × 860 mm × 2100 mm
VBM-300500 Liters300 kgs3HP1280 mm × 990 mm × 2240 mm
VBM-500830 Liters500 kgs3HP1580 mm × 990 mm × 2400 mm
VBM-7501250 Liters750 kgs3HP1600 mm × 1250 mm × 2400 mm
VBM-10001680 Liters1000 kgs5HP1920 mm × 1540 mm × 2950 mm
VBM-15002500 Liters1500 kgs5HP2060 mm × 1660 mm × 3250 mm
VBM-20003400 Liters2000 kgs7.5HP2260 mm × 1900 mm × 3400 mm
VBM-25004200 Liters2500 kgs7.5HP2450 mm × 2000 mm × 3600 mm
VBM-30005000 Liters3000 kgs10HP2500 mm × 2050 mm × 3800 mm
VBM-50008400 Liters5000 kgs20HP3050 mm × 2560 mm × 4500 mm
VBM-1000017000 Liters1000 kgs30HP3300 mm × 2700 mm × 6000 mm


※ Specifications and design characteristics are subject to change without prior notice.
